Hyper-V: How To Use Virtualization In Windows 11 And 10

Manual for Hyper-V in Windows 11 and 10: How to virtualize any working framework utilizing the Microsoft arrangement. Virtualization arrangements unquestionably need no presentation because of programming like Microsoft Hyper-V.

It is feasible to make virtual machines in Windows and introduce any working framework inside them, including the main Linux conveyances.

The benefit is that you can show at least one working framework to stack them in virtual machines ( visitors ) close to the form of Windows you use as the host framework.

Brought into the world of Windows Server frameworks, Hyper-V is an answer that can be utilized efficiently, even in the client renditions of the Microsoft working framework.

The stage needs to be pre-introduced and can be empowered in Windows 10 and 11 by squeezing the essential blend Windows+R, composing discretionary highlights, and pressing Enter. Checking the Hyper-V box introduces the local Microsoft hypervisor; be that as it may, a framework restart is required.

Hyper-V is installable in Ace, Schooling, and Undertaking releases of Windows 10 and 11; with a straightforward stunt, you can introduce Hyper-V in Windows 10 and 11 Home. The hypervisor is the focal and significant part of a virtualization arrangement: Hyper-V is “local” since it runs straightforwardly on the host framework equipment.

Execution is, in this manner, at the most significant levels, and the client can profit from the virtualization expansions carried out in equipment and empower capable from the Profiles (press CTRL+SHIFT+ESC to open the Undertaking Supervisor, select the Exhibition tab, then really look at that close to Virtualization is accounted for Empowered ).

How To Use Hyper-V In Windows 10 And 11, In A Nutshell

We have dedicated many articles to Hyper-V. This time we present a brief guide to Hyper-V, trying to highlight the main aspects. After installing Hyper-V as indicated above, the platform is ready to be used: the advice is to type Hyper-V in the Windows search box. Two entries will appear in Hyper-V Quick Create and Hyper-V Management Console.

If not, we suggest typing Windows Administrative Tools in the search box: Hyper-V Quick Create and Hyper-V Management Console are found here. Hyper-V Quick Create gives you access to a routine that helps you create a Windows or Linux virtual machine in seconds. The second choice option, i.e., Hyper-V management console, is a more complex tool that allows you to check, for example, the running virtual machines, those switched off, and change the configuration of individual devices and the entire virtualization system.

By choosing Hyper-V Quick Create, you can select from the left column, for example, a version of Ubuntu Linux to run as a virtual machine. Apart from downloading the VHDX image, which may take some time depending on the speed of your connection, the Ubuntu installation is ready to use: you only need to set aspects such as keyboard layout, language, time zone, and user accounts.

Alternatively, clicking on Local installation source makes it possible to switch any ISO image previously downloaded and saved locally to Hyper-V. One can then install a Linux distribution, download Windows 11 and try the system without changing the PC’s configuration (even preview versions of Windows 11 ).

You can use the Windows 10 ISO or the Windows 7 ISO to install and use programs that are not compatible with Windows 11. Thanks to Hyper-V, it is possible to start the backup copy of the Windows installation taken from a physical PC: even in the free version Macrium viBoot allows you to create an image of a system and then run it as a Hyper-V virtual machine, which is nothing short of outstanding.

Before creating a Hyper-V virtual machine, always click on More options and assign it an easily identifiable name. Hyper-V also allows you to simulate the Secure Boot feature, whose activation has become an essential requirement for installing Windows 11, even if the controls can be bypassed and Windows 11 can be installed on non-compatible PCs.

It is also possible to modify the Windows 11 ISO by inserting files that allow you to bypass the checks at the start of the installation. We have also seen how to create a customized ISO to have a Windows 11 that installs itself with all the most valuable programs, which is also very useful with Hyper-V. In addition to the virtual machine’s name, you can set the virtual switch to use by clicking on More options. By default, Hyper-V uses the Default switch: Hyper-V switches allow you to establish if and how a virtual machine can connect to the Internet and if, for example, it has visibility on the local network (and is, in turn, reachable from other devices connected via LAN).

By clicking on Create a virtual machine and then on Connect, Hyper-V will allow you to create and then start the virtual machine By default, the virtual machine is turned off by clicking on Connect: with a click on Start, it will be started. Using an ISO will create the standard installation of the corresponding operating system, precisely as if you were in front of a physical machine.

Closing (“X” at the top right) the window of a virtual machine will not be “suspended” nor stopped: you can verify this by typing Hyper-V Management Console in the Start menu. As you can see in the image, for example, the WIN11-VM virtual machine continues to run. With a simple double click on its name, you can go back to administering it in graphic or text mode, depending on the operating system installed.

By right-clicking on the virtual machine or referring to the items in the lower correct box, you can turn off the device as if you were to cut off the power to a physical PC, shut it down in a canonical way, save it to resume work from the point where you left it, restart the virtual machine ( Reset ), suspend it or create a checkpoint.

To delete a Hyper-V virtual machine, it must be turned off: only in this way will the Delete item appear. However, the corresponding VHDX file will continue to be stored in the folder where Hyper-V holds virtual machine images. This folder is in the Hyper-V Settings within the Virtual Hard Disks section. Hyper-V also does not immediately delete the VHDX file of the virtual machine because the user may later want to use it to create a new virtual machine.

To access the path where the VHDX files are stored by default, it is usually enough to type Hyper-V in the Start menu search box, select the Hyper-V folder, and finally, Virtual hard disks.

A Hyper-V checkpoint is a sort of “snapshot” that captures a snapshot of the virtual machine’s configuration at an exact moment. If you plan to make a significant change to your virtual machine configuration, you can create a checkpoint that you can recover in case something goes wrong.

In fact, by clicking on Restore, the virtual machine’s configuration will automatically be restored to the state it was in when the checkpoint was created. To make sure that the virtual machine is visible on the local network by other systems and can, in turn, reach them, type it is necessary to click on Manage virtual switches in the right column of the Hyper-V console and then select New virtual switch virtual network, give it, for example, the name EXT and finally select the External network option.

The virtual machine will thus be assigned an IP address belonging to the local network by the DHCP server configured in the LAN (for example, by the physical router). This virtual machine will appear on other devices like any other biological system. You can change its configuration in real-time by clicking on the File, Settings menu (or pressing CTRL+O ) in the virtual machine.

For example, acting on the Network card and selecting the EXT virtual switch created just now, this will be immediately used in the virtual machine. With Windows 11, we have verified that the simultaneous presence of Virtualbox on the same machine generates the error 0x80070490 when creating a new virtual network card (switch).

To resolve it is currently necessary to uninstall Virtualbox. The same account must belong to the Remote Desktop Users group to access a Windows virtual machine with a particular user account. To add a Windows account to that group, type cmd in the search box then choose Run as administrator, and finally type the following: net local group “Remote Desktop Users” username /add Instead of a username, specify the user account’s name to add to the Remote Desktop Users group.
